deck¶

The deck section defines the visual blocks in your WBR report. Blocks are rendered in order, top to bottom.

deck:
  - block:
      ui_type: 6_12Graph
      ...
  - block:
      ui_type: 6_WeeksTable
      ...

Block types¶

`ui_type`	Description
`6_12Graph`	Trailing 6 weeks + 12 months chart with summary table
`6_WeeksTable`	Trailing 6 weeks data table
`12_MonthsTable`	Trailing 12 months data table
`section`	Section header or divider
`embedded_content`	iframe from external URL

6_12Graph¶

The signature WBR visualization: trailing 6 weeks + trailing 12 months on a shared x-axis, with a summary table (last week, MTD, QTD, YTD, and period-over-period comparisons).

6_12Graph example

- block:
    ui_type: 6_12Graph
    title: Ad Impressions (Millions)
    y_scaling: "##.2MM"
    x_axis_monthly_display: trailing_twelve_months
    metrics:
      Impressions:
        line_style: primary
        graph_prior_year_flag: true
        legend_name: Impressions

Block-level parameters¶

Field	Values	Default	Description
`title`	String	—	Text at the top of the block
`y_scaling`	Format string	—	Y-axis number formatting
`x_axis_monthly_display`	`trailing_twelve_months`, `fiscal_year`	`trailing_twelve_months`	Monthly axis range

Per-metric parameters¶

Field	Values	Default	Description
`line_style`	`primary`, `secondary`, `target`	`primary`	Visual prominence. `target` shows markers only (no line).
`graph_prior_year_flag`	`true`, `false`	`true` for primary/secondary	Overlay prior year data
`legend_name`	String	Metric name	Label in chart legend

Recommend max 3 metrics per chart (primary + secondary + target).

Multi-metric example¶

- block:
    ui_type: 6_12Graph
    title: Total Page Views (Millions)
    y_scaling: "##MM"
    metrics:
      PageViews:
        graph_prior_year_flag: true
        legend_name: Page Views
      PageViews Target:
        line_style: target
        graph_prior_year_flag: false
        legend_name: Page Views - Target
      MobilePage_Views:
        line_style: secondary
        graph_prior_year_flag: true
        legend_name: Mobile Page Views

6_WeeksTable¶

6_WeeksTable example

Trailing 6 weeks of data plus QTD and YTD. Define each row explicitly.

- block:
    ui_type: 6_WeeksTable
    title: "Page Views Actual vs Plan Summary"
    rows:
      - row:
          header: "Page Views"
          style: "font-weight: bold; background-color: LightGrey; text-align:left;"
      - row:
          header: "Actual"
          metric: PageViews
          style: "text-align:right;"
          y_scaling: "##MM"
      - row:
          header: "YOY"
          metric: PageViewsYOY
          style: "font-style: italic; text-align:right;"
          y_scaling: "##.1%"

Row parameters¶

Field	Required	Description
`header`	Yes	Row label. Leave blank for an empty spacer row.
`metric`	No	Metric name. Omit to create a section header row.
`y_scaling`	No	Number format for this row's values
`style`	No	CSS properties applied to the header cell (e.g., `font-weight: bold; text-align: right;`)

12_MonthsTable¶

12_MonthsTable example

Same structure as 6_WeeksTable but shows trailing 12 months. Also supports x_axis_monthly_display.

- block:
    ui_type: 12_MonthsTable
    title: "Page Views Actual vs Plan Summary"
    x_axis_monthly_display: trailing_twelve_months
    rows:
      - row:
          header: "Actual"
          metric: PageViews
          style: "text-align:right;"
          y_scaling: "##MM"

Tip

6_WeeksTable and 12_MonthsTable work best when displayed together side-by-side for the same metrics.

Section break¶

- block:
    ui_type: section
    title: "Customer Experience"    # or "" for a plain divider

Embedded content¶

Display external content in an iframe.

- block:
    ui_type: embedded_content
    source: "https://your-dashboard-url"
    height: 700px
    width: 2000px

Use for Looker dashboards, Google Sheets, Tableau, static images, etc.
